Precision CNC Punched Aluminum 5052 L-Shaped Mounting Brackets for Electronic Enclosures

Highlight

Precision CNC Punched Aluminum L-Shaped Mounting Brackets for Electronic Enclosures
Custom L-Type Aluminum Mounting Brackets
Durable Aluminum Fixing Brackets for Enclosure Assembly

Product Description

Service Process for Precision CNC Punched Aluminum L-Shaped Mounting Brackets for Electronic Enclosures

1. Pre-Production Collaboration

(1) Requirement Confirmation
Confirm bracket application, overall dimensions, thickness, bending angle, hole patterns, tolerance requirements, surface treatment, order quantity, and delivery schedule.

(2) Drawing & Specification Review
Review 2D technical drawings covering hole locations, bend radius, edge details, and dimensional tolerances.

(3) DFM & Bending Analysis
Analyze punching and bending feasibility, control bend accuracy, and ensure fitment with electronic enclosure assemblies.

2. Process Planning & CNC Punching

(1) Material Selection
Select aluminum alloys such as 5052 or 6061 based on strength, formability, and corrosion resistance requirements.

(2) CNC Punch Programming
Develop CNC punching programs to process mounting holes, slots, and cutouts with consistent positioning accuracy.

(3) Bending Process Planning
Plan press brake bending processes to achieve accurate L-shaped angles and dimensional stability.

3. Production & Quality Control

(1) Punching & Bending
Perform CNC punching followed by precision bending to form L-shaped brackets with clean edges and accurate angles.

(2) Dimensional Inspection
Inspect hole positions, bend angles, overall dimensions, and flatness using calibrated measuring tools.

(3) Surface Preparation
Deburr edges and prepare surfaces to ensure safe handling and consistent surface treatment quality.

4. Post Processing & Delivery

(1) Surface Treatment
Apply anodizing, powder coating, or other surface treatments as required for corrosion protection and appearance.

(2) Cleaning & Packaging
Clean finished brackets and package them to prevent deformation or surface damage during transport.

(3) Delivery
Deliver finished mounting brackets according to agreed logistics arrangements and production schedules.

Common Materials for Aluminum L-Shaped Mounting Brackets

1. Aluminum 5052

Description:
An aluminum alloy suitable for bending and forming applications.

Characteristics:
Good formability and corrosion resistance.

Application:
Used for L-shaped mounting brackets requiring precise bending.

2. Aluminum 6061

Description:
High-strength aluminum alloy for structural brackets.

Characteristics:
Better strength with good machinability.

Application:
Applied to mounting brackets requiring higher load capacity.

Why Choose Waltay for Aluminum L-Shaped Mounting Brackets

1. Sheet Metal Processing Expertise

• Stable CNC punching and bending capability
• Accurate control of hole positions and bend angles

2. Customization Support

• Custom sizes, hole patterns, and angles supported
• Drawing-based production for enclosure applications

3. Quality Control System

• Dimensional and angle inspection
• Consistent quality across production batches

4. Efficient Response & Delivery

• Fast quotation after drawing review
• Stable lead times for electronic enclosure projects

5. One-Stop Manufacturing Solution

CNC punching, bending, surface treatment, inspection, and packaging integrated for mounting bracket production.
