Precision Cast Aluminum Housing for Medical Diagnostic Equipment with High Accuracy

Highlight

Precision Cast Aluminum Housing for Medical Diagnostic Equipment
High Accuracy Aluminum Equipment Enclosure
Stable Structural Housing for Medical Devices

Product Description

Service Process for Precision Cast Aluminum Housing for Medical Diagnostic Equipment

1. Pre-Production Collaboration

(1) Requirement Confirmation
Confirm housing application, overall dimensions, wall thickness, structural features, mounting interfaces, tolerance requirements, surface finish, order quantity, and delivery schedule.

(2) Drawing & Design Review
Review 2D drawings or 3D CAD models detailing internal structure, mounting points, openings, and critical tolerances.

(3) DFM & Casting Feasibility Analysis
Analyze casting structure, wall thickness uniformity, draft angles, and machining allowances to ensure manufacturability and dimensional stability.

2. Casting & Process Planning

(1) Material Selection
Select suitable aluminum casting alloys such as ADC12 or A356 based on strength, dimensional stability, and surface quality requirements.

(2) Mold & Process Planning
Design and prepare casting molds, define gating systems, and plan post-machining processes for precision features.

(3) Process Optimization
Optimize casting parameters to reduce porosity, improve surface integrity, and ensure consistent structural quality.

3. Production & Quality Control

(1) Precision Casting
Produce aluminum housings using controlled casting processes to achieve stable structure and repeatable dimensions.

(2) Post Machining
Perform CNC machining on critical interfaces, mounting holes, and reference surfaces to meet precision assembly requirements.

(3) Inspection & Verification
Inspect dimensions, wall thickness, flatness, and critical mounting features using calibrated measuring equipment.

4. Post Processing & Delivery

(1) Surface Treatment
Apply painting, powder coating, or anodizing as required to enhance corrosion resistance and appearance.

(2) Cleaning & Protection
Clean housings to remove residues and protect surfaces to prevent damage during handling and transport.

(3) Packaging & Delivery
Package housings with protective materials and deliver according to agreed medical equipment project schedules.

Common Materials for Cast Aluminum Medical Equipment Housings

1. Aluminum Alloy ADC12

Description:
A widely used die-casting aluminum alloy.

Characteristics:
Good castability, dimensional stability, and surface finish.

Application:
Used for medical equipment housings requiring complex structures.

2. Aluminum Alloy A356

Description:
High-quality aluminum casting alloy.

Characteristics:
Better mechanical properties and structural strength after heat treatment.

Application:
Applied to medical diagnostic equipment housings requiring higher strength and reliability.

Why Choose Waltay for Cast Aluminum Medical Equipment Housings

1. Casting & Machining Integration

• Stable control of casting quality and post-machining accuracy
• Experience with structural aluminum housings

2. Customization Support

• Fully custom designs based on drawings or specifications
• Support for prototype and batch production

3. Quality Control System

• Dimensional inspection and structural verification
• Consistent quality across production batches

4. Efficient Response & Delivery

• Fast quotation after drawing review
• Stable lead times for medical equipment projects

5. One-Stop Manufacturing Solution

Casting, CNC machining, surface treatment, inspection, and packaging integrated for aluminum housing production.
